Description
Drum pulper is a pulping equipment for the recycled fibers,provides maximum retention of fiber physical characteristics, minimum breakdown of contaminants, clean impurities and high quality of accept.
01
Drum Pulper for Paper Making Machinery Pulping Equipment
description1
Drum Pulper Structure
The drum pulper consists of two groups: the rotating part and the driving system. the rotating part is composed of the mixing section, the pulping section and the screening section. the driving system is composed of the support rolls , the transmission device and the lubrication unit.
Working Principle
The waste paper enters the mixing section and pulping section of the drum pulper and gets fully disintegrated by gentle rubbing in the pulping section, and then goes forward to the screening section, where it is diluted by the spraying shower, and the accept stock goes into the bottom vat, waste plastics are washed away and discharged from the reject discharge outlet.
Feature
Compared with the D-type pulper, the drum pulper has the advantages of easy system, low energy consumption and low maintenance cost.
● Gentle defiberizing of furnish with specially shaped internals;
● Lifting plates in staggered arrangement constant, smooth stock falling and tumbling;
● Stock moves slowly towards the screening section due to the drum declination;
● No cutting forces, No aggressive shearing;
● Minimum breakdown of contaminants;
● Maximum retention of fiber physical characteristics;
● Lowest power consumption;
● Minimum maintenance requirements;
● Excellent quality stock;
● Enables all grades of recycled furnish;
FAQ
-
Q: Are you a factory or a trading company?
Shandong Haitian Paper Machinery Co.,Ltd. is a professional factory of culture paper machine, cardboard paper machine, kraft paper machine and specific paper machine. -
Q: How is the quality of your equipment?
-
Q: What kind of paper machine your factory produce?
-
Q: What's your quality guarantee?
-
Q: What's benefit will you bring?
