description1
Roll Types |
Guide Roll/Wire Roll/Felt Roll |
Max Face Length |
12000mm |
Roll diameter |
200-2000mm |
Coating type and thickness |
Customer's requirement |
Dynamic Balancing |
G1.0, with dynamic deflection curve, other info required by customer |
Roll body material |
Q235B,Q345B |
Shaft head |
Cast steel/Forged 42CrMo |
The guide roller is composed of a roller core, a bracket, a baffle plate, an idler roller and a bearing connection. The surface of the idler roller is a concave arc surface, which can automatically center the steel pipe on the idler roller. The setting of the baffle plate can limit and fix the steel pipe. Prevent the steel pipe from detaching from the roller, the roller core can roll with the frame during use, the roller rotates with the roller core through the bearing, reducing rolling friction, small rolling resistance, prolonging the service life of the guide roller, and facilitating the post-processing of the steel pipe , to improve the processing efficiency of steel pipes.
Max roll/cylinder face length 11900mm
Max roll/cylinder OD 2000mm
Max balancing speed 3000m/min( Roll for Rewinder machine)
